The Function Signal Generator: Principles and Operational Characteristics
A function signal generator is an electronic signal source capable of synthesizing a variety of standard waveforms. Typical outputs include sinusoidal, triangular, square, and sawtooth waves, with operational frequencies spanning from sub-hertz to several hundred kilohertz. This versatility renders the instrument indispensable across numerous electronic testing and development contexts. The triangular and sawtooth waveforms, characterized by linear voltage ramps, are particularly useful in applications requiring a precisely controlled rate of change, such as sweep oscillators for cathode-ray oscilloscopes (CROs) and for driving the X-axis of X-Y recorders.
Key Functional Attributes
Several advanced features enhance the utility of function signal generators, especially when integrated with CROs for comprehensive system analysis:
- Simultaneous Multi-Waveform Generation: These instruments can produce two discrete waveforms concurrently via separate output terminals. For example, a square wave may be applied to a device under test (e.g., for measuring audio system linearity). In contrast, a synchronous sine wave drives the horizontal deflection amplifier of an oscilloscope, enabling direct visual observation of the response.
- Coherent Frequency Outputs: Function signal generators can output different waveform types at identical frequencies. A typical implementation is to generate triangular and sinusoidal waves simultaneously. This is achieved through precise internal timing, ensuring phase coherence such that the zero-crossing points of both waveforms are aligned.
- External Phase-Locking Capability: Sophisticated models offer phase-lock functionality to an external reference signal. This permits one signal generator to synchronize its output phase to another, with a user-adjustable phase offset. Furthermore, a signal generator can be locked to a harmonic of an external source, facilitating the synthesis of complex waveforms by combining fundamental and harmonic components. Phase-locking to a high-stability frequency standard is also possible, thereby transferring the reference’s accuracy and stability to all generated waveforms.
Operational Architecture
The core operation of a typical function signal generator involves three principal modes within its circuitry:
- Frequency Control Network: The output frequency, adjustable over a broad range (e.g., 0.01 Hz to 100 kHz), is controlled by adjusting the current supplied to an integrator circuit. This integrator is fundamental to generating the core waveform shapes.
- Dual Current Source Operation: A voltage-controlled subsystem manages two current sources. The first source supplies a constant current to the integrator, producing a linearly increasing output voltage. The slope of this ramp, and thus the output frequency, is directly proportional to the magnitude of this current.
- Voltage-Controlled Switching via Comparator: A voltage comparator or multi-vibrator circuit monitors the integrator’s output. When the voltage reaches a predetermined upper threshold, the comparator changes state. This action disables the first current source and enables the second, which injects a reverse current into the integrator, causing its output to decrease linearly. When the comparator reaches a lower threshold, it toggles again, re-engaging the first source. This continuous integration process yields a triangular waveform at the integrator output, while the comparator output provides a square wave of identical frequency. A subsequent waveshaping circuit, typically a resistor-diode network, progressively attenuates the peaks of the triangular wave to approximate a sinusoidal output with low distortion (often <1%).
Supplementary Technical Definitions
- Multivibrator: A regenerative electronic circuit that utilizes positive feedback to generate non-sinusoidal oscillations, primarily square or rectangular waves. It operates by rapidly switching between two quasi-stable states.
- Utility in Conjunction with a CRO: The primary role of a function signal generator is to serve as a flexible stimulus for electronic circuits. When used with a CRO, it provides the controlled input signal needed to visualize and quantify a system’s response, making it a cornerstone instrument for waveform analysis, frequency response testing, and troubleshooting.
